CHEMICAL PROPULSION

TEIDE
Hybrid Propellant

Chemical hybrid rockets for micro-launchers,
small upper stages, and sounding rockets.

APPLICATIONS

TEIDE Hybrid propulsion systems to cover satellites multiple needs.

ORBIT RAISING

UPPER STAGES

RE-POSITIONING

DEORBITING

Our TEIDE hybrid rockets can be fully customized and different types of solid fuels can be used depending on customer needs. We have been casting fuel grains up to 200 kg, acquiring a wide expertise on fuel types and properties.

PARAFFIN

WAX

5

TRL

H2O2

HTP HIGHLY STABILIZED

MAIN FEATURES

Thrust Different systems from 100 N to 10 kN
Specific Impulse From 285 s at smaller scale, up to 300 s
Thrust time Tested up to 80 s, capabilities dependent on configuration
Multiple restarts Yes
Throttleability 1:10
Time to market 1.5 years (for a complete propulsion module under customer’s specs)
Propellant combinations 90-95% Hydrogen Peroxide – plastics
